The award-winning HYPERION is a fully discrete, true balanced, class AB power amplifier. The power output rated at conservative 80W per channel into 8ohms, 120W into 4ohms (both channels driven, rms).
The 300VA power transformer is custom-made for audio with copper shield. 18 pieces of large reservoir capacitors (147,600uF) and fast switching action schottky diode, supplying more than adequate DC power rails to the modular power amplifier.
True balanced input are being amplified (both +ve and -ve signal w.r.t gnd) by the modular power amplifier circuitry. Each channel is equipped with 4 pairs of output transistors.
NOTE: DENAFRIPS power amps are true balanced. Please do not connect the amplifier' speaker output to the sub-woofer high level input. Such a connection may potentially damage the amplifier. Please contact us should you need to integrate the sub-woofer to the stereo system.
| Description | Parameters |
|---|---|
| Highlight | Class-AB, True Balanced, Fully Discrete Power Amp |
| Input | XLR |
| Input Impedance | 22k Ohms |
| Input Sensitivity | 1.8Vrms |
| Output | 4mm Speaker Binding Post |
| Gain | 26dB |
| Output Power | 80w RMS per channel into 8ohms |
| AC Power Requirement | 100-240VAC, 50/60Hz (Worldwide Voltage) |
| Power Consumption | 0.5W (Standby), 35W (Idle), 234W (Operational) |
| Frequency Response | 10-80k（-2.2dB） |
| THD+N | 0.00% |
| S/N Ratio | 125dB |
| Dynamic Range | >121dB |
| Stereo Crosstalk | -110dB |
| Dimension | 320W x 380D x 100H mm |
| Weight | 16.5 Kg |
| Color | Silver / Black |
